Convoluted Ptfe Fuel Hose
Size: an4 an6 an8 an10 an12 an16 an20
Cover: Black Nylon or Stainless Steel Braided
Application: Oil cooler system
Product introduction:
Model Number: AN4 AN6 AN8 AN10 AN12 AN16 AN20
Product name: convoluted ptfe fuel hose
Material: PTFE+Nylon/SS braided cover
Size: an4 an6 an8 an10 an12 an16 an20
Cover: Black Nylon or Stainless Steel Braided
Application: Oil cooler system
Length: 1m 3m 6m or customized
Standard: SAE J1532
Product Description:
Highly durable oil & fuel hose.An3 4an 6an 10an 12an 16an an20 Braided
Oil Hose
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
The hose is made of Rubber with a braiding of zinc plated steel. The hose has a temperature range of -30 °C to 80 °C (for fuels with up to 30% benzene, -30 °C to +40 °C). The hose is suitable for commercial fuels such as petrol, diesel, heating oil as well as water and air.
AN4-6-8-10-12-16-20 PTFE STAINLESS STEEL NYLON BRAIDED OIL COOLER HOSE
PTFE Hose and Fittings can be free mixed, CONTACT US get more info. Nylon /SS Braided PTFE Fuel Line: Best for Oil gas line, Fuel hose, Clutch hose, Recommended for Alcohol, Nitro, transmission, clutch, nitrous, power steerig, oiling, hydraulic & vacouum applications. Universal Models: The fuel line hose fits different brands of different cars.Just choose the right size.
Fit forE85
Safety Features For Your Protection: The product has good flame retardancy and excellent corrosion resistance.
Long Life: Inner corePTFE has excellent corrosion resistance. It is maintenance free and precision engineered to increase life. Professional Installer is Highly Recommended .
Features: Oil resistance, Aging resistance, Corrosion resistance, High and low temperature resistance Superior heat dissipation
Product parameters
Black nylon oil cooler rubber hose
|
SN |
I.D |
O.D |
W.P |
B.P |
Minimum Bend Radius |
Temperature Range |
|
|
mm |
mm |
MPa |
MPa |
mm |
min |
max |
|
|
4 |
5.56 |
11.17 |
3.45 |
13.8 |
50.8 |
-40 |
148.9 |
|
6 |
8.71 |
14.22 |
3.45 |
13.8 |
63.5 |
-40 |
148.9 |
|
8 |
11.13 |
17.2 |
3.45 |
13.8 |
88.9 |
-40 |
148.9 |
|
10 |
14.29 |
20.83 |
3.45 |
13.8 |
101.6 |
-40 |
148.9 |
|
12 |
17.46 |
24.38 |
3.45 |
13.8 |
114.3 |
-40 |
148.9 |
Stainless steel wire braided oil cooler rubber hose
|
SN |
I.D |
O.D |
W.P |
B.P |
Minimum Bend Radius |
Temperature Range |
|
|
mm |
mm |
MPa |
MPa |
mm |
min |
max |
|
|
4 |
5.56 |
11.13 |
7 |
42 |
50.8 |
-40 |
148.9 |
|
6 |
8.73 |
13.89 |
7 |
42 |
63.5 |
-40 |
148.9 |
|
8 |
11.12 |
16.28 |
7 |
35 |
88.9 |
-40 |
148.9 |
|
10 |
14.27 |
20.24 |
7 |
35 |
101.6 |
-40 |
148.9 |
|
12 |
17.47 |
23.82 |
7 |
26.3 |
114.3 |
-40 |
148.9 |
|
16 |
22.22 |
29.36 |
5.2 |
17.5 |
139.7 |
-40 |
148.9 |
FAQ
Q: Can you produce the hose with my own brand?
A: Yes, we have been offering OEM service for 10 years.
Q: Can you send us a sample to test quality before ordering?
A: Yes, we can provide sample by free but the freight and other charges is payed by the customers.
Q: Could we pay a visit to your factory?
A: Yes, you are always welcome to visit our factory.
Q: Can you help us do the custom clearance?
A: Yes, we can. We can help you find a professional custom clearance company to do it.
Q: Can we get the goods without your company name to export?
A: Yes, we can. We are allowed to use your designated agent's name if you have one.
Q: Can you produce goods with special specification?
A: First of all, we need to know the specification in details, and then we need to check with our technology department. We will give customers satisfying reply as soon as possible.
