7 Inch Diameter Pvc Pipe
Material: NBR PVC Silicone EPDM PP ABS PE
Size: Various Size
Color: Each pantone color
Product introduction
Products: 7 inch diameter pvc pipe
Hollow Tubing: Plastic rigid sofe pipe
Material: NBR PVC Silicone EPDM PP ABS PE
Size: Various Size
Color: Each pantone color
Samples: Stock samples is free
Advantage
1 Chemical resistance and insulation.
2 Stable in dimension, density in material, uniform in thickness.
3 Anti-pressure, non-inflammability, high intensity.
4 Small friction, no scaling, effect liquidity.
5 Durable with service life 30-50 years.
6 Pipe end type: Plain end, bell end, gasket end.
PVC pipe (divided into PVC-U pipe, PVC-UH pipe and PVC-O pipe) is made of PVC resin, stabilizer and lubricant, and then extruded by hot pressing. It is the first plastic pipe to be developed and applied.
PVC-U pipe has strong corrosion resistance, easy adhesion, low price and hard texture. However, due to the seepage of PVC-U monomer and additives, it is only suitable for water supply system with conveying temperature less than 45 ºC. Plastic pipes are used for drainage, wastewater, chemicals, heating and cooling fluids, food, ultra pure liquids, slurries, gases, compressed air and vacuum systems.
PVC-O pipe, is the latest evolution form of PVC pipe. The pipe made by special orientation processing technology will be extruded to produce PVC-U pipe by axial and radial stretching, so that the long chain molecules of PVC in the pipe will be arranged in biaxial direction, and a new type of PVC pipe with high strength, high toughness, high impact resistance and fatigue resistance will be obtained.
Chemically Stable Corrosion-resistant Non-toxic PVC Pipe with Detailed Pipe PVC Sizes for Underground Water Supplying Plant
Features
1. High toughness and good seismic performance.
2. The connection is reliable.
3. Low density, light weight, easy to handle and install.
4. Can resist a variety of chemical media corrosion.
5. Excellent hydraulic performance, the wear resistance coefficient is only 0.009.
6. Long service life, up to 50 years.
7. Good hygiene and environmental performance.
8. Better resistance to slow crack growth(SCG)and rapid crack propagation(RCP).
Product parameters
Normal Dia | Wall Thickness EN(mm) | ||||||
(mm) | PN 0.6 MPa | PN 0.8 MPa | PN 1.0 MPa | PN 1.25 MPa | PN 1.6 MPa | PN 2.0 | PN 2.5 |
| MPa | MPa | ||||||
Φ20 | 2 | 2.3 | |||||
Φ25 | 2 | 2.3 | 2.8 | ||||
Φ32 | 2 | 2.4 | 2.9 | 3.6 | |||
Φ40 | 2 | 2.4 | 3 | 3.7 | 4.5 | ||
Φ50 | 2 | 2.4 | 3 | 3.7 | 4.6 | 5.6 | |
Φ63 | 2 | 2.5 | 3 | 3.8 | 4.7 | 5.8 | 7.1 |
Φ75 | 2.3 | 2.9 | 3.6 | 4.5 | 5.6 | 6.9 | 8.4 |
Φ90 | 2.8 | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 | 10.1 |
Φ110 | 2.7 | 3.4 | 4.2 | 5.3 | 6.6 | 8.1 | 10 |
Φ125 | 3.1 | 3.9 | 4.8 | 6 | 7.4 | 9.2 | 11.4 |
Φ140 | 3.5 | 4.3 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
Φ160 | 4 | 4.9 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
Φ180 | 4.4 | 5.5 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
Φ200 | 4.9 | 6.2 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
Φ225 | 5.5 | 6.9 | 8.6 | 10.8 | 13.4 | 16.6 | |
Φ250 | 6.2 | 7.7 | 9.6 | 11.9 | 14.8 | 18.4 | |
Φ280 | 6.9 | 8.6 | 10.7 | 13.4 | 16.6 | 20.6 | |
Φ315 | 7.7 | 9.7 | 12.1 | 15 | 18.7 | 23.2 | |
Φ355 | 8.7 | 10.9 | 13.6 | 16.9 | 21.1 | 26.1 | |
Φ400 | 9.8 | 12.3 | 15.3 | 19.2 | 23.7 | 29.4 | |
Φ450 | 11 | 13.8 | 17.2 | 21.5 | 26.7 | 33.1 | |
Φ500 | 12.3 | 15.3 | 19.1 | 23.9 | 29.7 | 36.8 | |
Φ560 | 13.7 | 17.2 | 21.4 | 16.7 | |||
Φ630 | 15.4 | 19.3 | 24.1 | 30 | |||
FAQ
Q: Are you a manufacturer or a trading company?
A: We are a professional manufacturer in China.
Q: What is your sample policy?
A: We can supply the sample if we have ready parts in stock.
Q: Can you print text on the product according to customer requirements?
A: Yes, make labels according to your exact requirements.
Q: how can we guarantee quality?
A: Always a pre-production sample before mass production;Always final Inspection before shipment.
Q: Can you produce customized goods?
A: Yes, the size, diameter and length can be produced as per client's requirements.
Q: Do you accept OEM?
A: Yes, OEM is available.
