Pu Tube Pneumatic Pipe

Product introduction:

Name: pu tube pneumatic pipe

PU Tubing Pipe Material: PU( Polyurethane )

PU Tubing Pipe Size: 4mm 6mm 1/4"

Length: 25/50/100 meters

Working Pressure: 1 Mpa

Color: Transparent

Tubing Pipe Working Temperature: -30℃--70℃



Product Description:

* This PU tubing is built to last and withstand wear and tear. It is also resistant to kinking.

* Great for use with automation machinery and pneumatic lines.

* You will not have to constantly replace old. It is ultra-durable and will not become brittle or crack in time. It is also resistant to kinking so can bend so it will perform as designed.

* Extremely flexible, PU is suited for genera low pressure industrial applications for the conveyance of liquids and solids of suitable granular size.

* High quality, non-toxic, flexible, Smooth inner surface for easy flow and easy cleaning.



1.Classical design, durable ai control design

2.Engery saving and environmental protection with big low rate, safety and precision

3.Can work at the low pressure, smartness for on and off, good seal performance

4.Single action and double action types for your selection

5.Widely used in the food, machin, industry, abstersion, lanification, printing and other area



Features

Good wear ability, smooth surface, low resistance, anti-rustiness and anti-scaling.

Flexible, easily to be bent into all kinds of shapes, easy to install.

High chemical and hydrolysis resistance(-40℃~120℃), can transfer compressed air, water, oil, chemical liquid and so on.



It is widely used in Light trucks, car hydraulic brake system, power steering tube, forklifts and loading trucks, mining vehicles, kai heavy machinery, ships, and other works of hydraulic mechanical transmission and control system piping, paint and liquid resin spraying high-pressure pipe, air conditioning.



Product parameters

Size (O.DxWall Thickness)	Weight per meter (g/m)	Tensile Strength (kgf/m²)	Working Pressure (MPa)	Bursting Pressure (MPa)	Bending Radius (mm)
3mmx0.5mm	4.3	10	3	4.5	18
4mmx0.75	8.4	13	3.1	5.5	20
4mmx1mm	10.4	16	4.5	6.8	30
5mmx1mm	13.8	22	3.4	6.5	35
5mmx1mm	17.3	34	3.2	6.3	40
6mmx1mm	24.2	43	2.6	5.7	50
8mmx1mm	31.1	62	2.7	4.5	65
10mmx1mm	37.8	70	2.8	5.6	65
12mmx1.5mm	54.4	101	3.2	5.7	70
14mmx1.5mm	64	125	2.2	5.6	80
15mmx1.5mm	70	140	2	5.4	90
16mmx2mm	96.7	190	2.8	5.4	130
18mmx1.5mm	85.5	210	2.3	3.6	155
23mmx2mm	145.1	260	2.1	3.3	120
3/16"x 0.75mm	10.4	18	3.3	6.3	35
5/16" x 1mm	24	40	2.5	5.6	50
1/4" x 1mm	18.5	38	2.7	5.3	45
3/8" x 1.5mm	41.6	65	2.8	6.1	50
1/2" x 1.5mm	58.1	110	3	5.5	80
5/8" x 1.5mm	74.5	175	2.7	5	125



FAQ

Q: Can you produce the hose with my own brand?

A: Yes, we have been offering OEM service for 10 years.



Q: Can you send us a sample to test quality before ordering?

A: Yes, we can provide sample by free but the freight and other charges is payed by the customers.



Q: Could we pay a visit to your factory?

A: Yes, you are always welcome to visit our factory.



Q: Can you help us do the custom clearance?

A: Yes, we can. We can help you find a professional custom clearance company to do it.



Q: Can we get the goods without your company name to export?

A: Yes, we can. We are allowed to use your designated agent's name if you have one.



Q: Can you produce goods with special specification?

A: First of all, we need to know the specification in details, and then we need to check with our technology department. We will give customers satisfying reply as soon as possible.
