Pneumatic Pu Hose

Product introduction:

Product Name: pneumatic pu hose

Material: PU/polyurethane

Length: 100m or 200m

Thickness: 1mm-5mm or up to your request

Size: 4*2.5mm 6*4mm 8*5mm 10*6.5mm 12*8mm 14*10mm, 16mm*12mm, etc

Color: transparent, red, blue, orange, black etc

Application: Pneumatic Component



Product Description:

ADVANTAGES

● 100% fresh material

● Customized logo available(MOQ request)

● Lightweight and low cost

● Widely range sizes and color for choose

● PU tube is widely used in compressed air systems, automation, food process, robotics etc.



Features

1.Durable, not easy to burst, a high quality PU tube

2.Smooth and flat, bright color, made of pure material, PU tube shows bright color, smooth and smooth hand feeling, no burr, strong light transmission

High center of gravity, thick wall, pressure and explosion proof



Characteristic:

Has excellent flexibility, the bevelling radius is small;

Good anti-knocking property;The nature is light;

The operating temperature and the workingpressure scope is wide;

Has the excellent chemical properties, the pressure loss is minimum;

Degree of hardness is constant, the service life is long;

Non-toxic, tasteless;

Custom-made color is doable, easy pipeline recognition, Confore to the ROHS environmental protection requirement.



Product parameters

Model Box Packing	Model Roll Packing	Model Short Length	Tube O.D	Tube I.D	Standrad Length
PU4*2.5-HZ	PU4*2.5-PZ	PU4*2.5	4mm	2.5mm	200M
PU6*4-HZ	PU6*4-PZ	PU6*4	6mm	4mm	200M
PU8*5-HZ	PU8*5-PZ	PU8*5	8mm	5mm	100M
PU8*6-HZ	PU8*6-PZ	PU8*6	8mm	6mm	100M
PU10*6.5-HZ	PU10*6.5-PZ	PU10*6.5	10mm	6.5mm	100M
PU10*8-HZ	PU10*8-PZ	PU10*8	10mm	8mm	100M
PU12*8-HZ	PU12*8-PZ	PU12*8	12mm	8mm	100M
PU12*10-HZ	PU12*10-PZ	PU12*10	12mm	10mm	100M
PU14*10-HZ	PU14*10-PZ	PU14*10	14mm	10mm	100M
PU16*12-HZ	PU16*12-PZ	PU16*12	16mm	12mm	100M
PU16*13-HZ	PU16*13-PZ	PU16*13	16mm	13mm	100M



FAQ

Q: Can you produce the hose with my own brand?

A: Yes, we have been offering OEM service for 10 years.



Q: Can you send us a sample to test quality before ordering?

A: Yes, we can provide sample by free but the freight and other charges is payed by the customers.



Q: Could we pay a visit to your factory?

A: Yes, you are always welcome to visit our factory.



Q: Can you help us do the custom clearance?

A: Yes, we can. We can help you find a professional custom clearance company to do it.



Q: Can we get the goods without your company name to export?

A: Yes, we can. We are allowed to use your designated agent's name if you have one.



Q: Can you produce goods with special specification?

A: First of all, we need to know the specification in details, and then we need to check with our technology department. We will give customers satisfying reply as soon as possible.
