Hydraul Hose For Forklift

Product introduction:
Product name: hydraul hose for forklift
Hose ID: 3/8''Inch 9.5mm
Wire OD: 17.5mm
Hose OD: 21.4mm
Work pressur: Mpa: 44.5 Psi: 6450
Burst pressure: Mpa: 180 Psi: 26000
Min. Bend Radius: 180mm
Weight: 0.78kg/m

Product Description:
Various hydraulic hoses
Made of high-quality synthetic rubber, it can produce various types of hoses and can also be customized according to your needs, It has the characteristics of good wear resistance, high pressure resistance, aging resistance, strong pulse ability and good bending performance of the pipe body.



Customize
The logo and surface treatment method (smooth or cloth) can be customized according to your requirements, making it flexible and soft, anti-aging and wear-resistant, and can withstand high pressure and small deformation.



Structure: Hydraulic rubber hose is made of inner rubber, middle rubber, steel wire reinforcement layer and cover rubber.



Feature: oil-resistant; heat-resistant, anti-aging; anti-cracking; wear-risistant; corrosion-resistant; ozone-resistant; fatigue-resistant



Application: For delivery Hydraulic Liquid or water-based liquid.

Product parameters

Specification inch/mm	layer number	W.P. Mpa	B.P. Mpa	Min.Bend Radius mm	Weight kg/roll	Measure cbm/roll	Unite price (USD/m)
1/4"	6	2	34.5	137.8	102	18/50m	0.038
5/16"	8	2	29.3	117.1	114	22.5/50m	0.0383
3/8"	9	2	27.6	110.2	127	27/50m	0.048
1/2"	13	2	24.1	96.5	178	34/50m	0.065
5/8"	16	2	18.9	75.8	203	40/50m	0.069
3/4"	19	2	15.5	62	241	70.5/50m	0.104
1"	25	2	13.8	55.1	305	67.5/20m	0.127
1-1/4"	32	2	11.2	44.8	419	43/20m	0.122
1-1/2"	38	2	8.6	34.5	508	53/20m	0.173
2"	51	2	7.8	31	635	68.4/20m	0.235



FAQ
Q: Can you produce the hose with my own brand?
A: Yes, we have been offering OEM service for 10 years.



Q: Can you send us a sample to test quality before ordering?
A: Yes, we can provide sample by free but the freight and other charges is payed by the customers.



Q: Could we pay a visit to your factory?
A: Yes, you are always welcome to visit our factory.



Q: Can you help us do the custom clearance?
A: Yes, we can. We can help you find a professional custom clearance company to do it.



Q: Can we get the goods without your company name to export?
A: Yes, we can. We are allowed to use your designated agent’s name if you have one.



Q: Can you produce goods with special specification?
A: First of all, we need to know the specification in details, and then we need to check with our technology department. We will give customers satisfying reply as soon as possible.
