Large Diameter Hdpe Water Pipe
Diameter: 20mm-1000mm
Outside Diameter: 20mm – 1600mm, or as your order
Feature: Durable
Type: Extruded
Usage: Construction Industry
Advantage: One stop procurement
Product Description:
Large diameter hdpe water pipe Feature:
HDPE pipe is formed by hot extrusion using advanced production technology and technology. It has corrosion resistance, smooth inner wall, low flow resistance, high strength, good toughness and light weight. After the PVC-U drainage pipe, the water supply HDPE tubes has become the second largest plastic pipe product in the world.
Advantage:
1. High corrosion resistance, resulting into a longer life
2. Extremely light weight and hence easy to handle
3. High fle ibility. High abrasion resistance. High impact strength.
4. Excellent water hammer characteristic helps, sustaining surges .
5. Excellent flow characteristics leading to significant energy savings.
6. Shifting soils no breakage. Earthquake resistance.
7. No infitration, helps maintaining the quality of fluids being conveyed
8. No trenches needed, resulting into easy and economical installation.
9. High UV resistance to scaling and biological build up -Allows fusion to eliminate leakages
Product parameters
Pressure | PN0.6MPa SDR 26 | PN0.8MPa SDR 21 | PN1.0MPa SDR 17 | PN1.25MPa SDR 13.6 | PN1.6MPa SDR 11 |
OD | Thickness | Thickness | Thickness | Thickness | Thickness |
(mm) | (mm) | (mm) | (mm) | (mm) | (mm) |
20 | 2.3 | ||||
25 | 2.3 | ||||
32 | 3 | ||||
40 | 3.7 | ||||
50 | 4.6 | ||||
63 | 3.7 | 4.7 | 5.8 | ||
75 | 4.5 | 5.6 | 6.8 | ||
90 | 4.3 | 5.4 | 6.7 | 8.2 | |
110 | 4.2 | 5.3 | 6.6 | 8.1 | 10 |
125 | 4.8 | 6 | 7.4 | 9.2 | 11.4 |
140 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
160 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
180 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
200 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
225 | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 |
250 | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
280 | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
315 | 12.1 | 15 | 18.7 | 23.2 | 28.6 |
355 | 13.6 | 16.9 | 21.1 | 26.1 | 32.2 |
400 | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 |
450 | 17.2 | 21.5 | 26.7 | 33.1 | 40.9 |
500 | 19.1 | 23.9 | 29.7 | 36.8 | 45.4 |
560 | 21.4 | 26.7 | 33.2 | 41.2 | 50.8 |
630 | 24.1 | 30 | 37.4 | 46.3 | 57.2 |
Application
PE water supply pipe can be used for general purpose pressure water transmission and drinking water transmission. His surface color indicates that his use is mainly for water-related pipes (water supply pipes), gas pipes in yellow, fire-fighting pipes in red and mining pipes.
There are mainly municipal buried water supply, building water supply (drainage), farmland irrigation, waterscape engineering and so on. In water supply pipeline engineering, PE water supply pipe will eventually replace UPVC pipe.
FAQ
Q: What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q: Can you send us a sample to test quality before ordering ?
A: Yes, we can provide sample by free.
Q: Can we get the goods without your company name to export ?
A: Yes, we can. We are allowed to use your designated agent's name if you have one.
Q: Can you produce goods with special specification ?
A: First of all, we need to know the specification in details, and then we need to check with our technology department. We will give customers satisfying reply as soon as possible
Q: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
