12 Inch Lay Flat Hose
Length: 10m/30m/50m/100m
Inch: 1/1.5/2/2.5/3/4/5/6/8
Colour: Blue or other colors customized
Size: 25/40/50/65/80/100/125/150/200
Application: Agriculture, Mining, Construction Dewatering
Feature: Anti-corrosion, Anti-UV, Flexible
Product introduction:
Name: 12 inch lay flat hose
Length: 10m/30m/50m/100m
Inch: 1/1.5/2/2.5/3/4/5/6/8
Colour: Blue or other colors customized
Size: 25/40/50/65/80/100/125/150/200
Application: Agriculture, Mining, Construction Dewatering
Feature: Anti-corrosion, Anti-UV, Flexible
Work pressure: 2-10bar
Logo: Customizable
Working temperature: -5°C to +65°C
Product Description:
Application
Widely used in agriculture and forestry irrigation, drainage in the fields of construction engineering, Italy introduced the latest technology, with strong tenacity polyeaster thread and imported law materials, extrusion technology for production at a time
Characteristics
Product is qualitative light, soft, anti-aging, high pressure, can in -5℃ up to 65℃ environment
PVC with high tensile strength Yarn Braided
Light weight, good flexiblity, anti-aging, anti-uv
Easy use&storage, different colors are available
Suitbale for conveying liquid materials in industry, agricultural irrigation, mines
Product Parameters
(1). Hi-strength terylene yarn and qualified PVC synthesis original materials.
(2). Light weight, good flexibility, bright color, smooth layer.
(3). Flat roll and easy for taking bak, convenient for moving and storage
(4). Working at low-temperature water, also high-temperature water.
(5). Anti-hi pressure, corrosion resistance and aging resistance.
(6). Applied to the lines of the auxiliaries for agricultural tools against the drought, project, mining, environment
protection, industry and so on, which is the idea liquid transferred hi-pressure hose.
(7). Applicabled operation at temperature -5°C to +65°C.
(8). Length and color are according customer's requirement
Product parameters
|
Item No.
|
type |
Working Pressure |
Weight |
Length |
Measure |
B.P |
|
Inch |
Bar |
Kg/m |
M |
M³ |
Bar |
|
|
TLH-06038 |
1-1/2" |
06 |
0.30 |
100 |
0.0294 |
12 |
|
TLH-06050 |
2 |
06 |
0.36 |
100 |
0.050 |
12 |
|
TLH-06054 |
2-1/2" |
06 |
0.49 |
100 |
0.062 |
12 |
|
TLH-06075 |
3" |
06 |
0.62 |
100 |
0.0832 |
12 |
|
TLH-06100 |
4" |
06 |
0.80 |
100 |
0.109 |
|
|
TLH-06125 |
5" |
06 |
1.15 |
100 |
0.152 |
|
|
TLH-06150 |
6" |
06 |
1.55 |
100 |
0.181 |
|
|
TLH-06200 |
8" |
06 |
1.95 |
100 |
0.267 |
|
|
TLH-08038 |
1-1/2" |
08 |
0.33 |
100 |
0.030 |
|
|
TLH-08050 |
2" |
08 |
0.475 |
100 |
0.053 |
|
|
TLH-08064 |
2-1/2" |
08 |
0.55 |
100 |
0.064 |
|
|
TLH-08075 |
3" |
08 |
0.65 |
100 |
0.085 |
|
|
TLH-08100 |
4" |
08 |
0.95 |
100 |
0.112 |
|
|
TLH-04250 |
10" |
04 |
2.8 |
50 |
0.140 |
|
|
TLH-04300 |
12" |
04 |
3.5 |
50 |
0.170 |
FAQ
Q: Can you produce the hose with my own brand?
A: Yes, we have been offering OEM service for 10 years.
Q: Can you send us a sample to test quality before ordering?
A: Yes, we can provide sample by free but the freight and other charges is payed by the customers.
Q: Could we pay a visit to your factory?
A: Yes, you are always welcome to visit our factory.
Q: Can you help us do the custom clearance?
A: Yes, we can. We can help you find a professional custom clearance company to do it.
Q: Can we get the goods without your company name to export?
A: Yes, we can. We are allowed to use your designated agent’s name if you have one.
Q: Can you produce goods with special specification?
A: First of all, we need to know the specification in details, and then we need to check with our technology department. We will give customers satisfying reply as soon as possible.
