Flexible Pvc Hose Braided 5/16"
Heavy Duty - Clear braided hose made of high pressure and high duty PVC with smooth interior and exterior that allows easy flow and flushing, light weight, BPA Free, non-toxic.
Durable Use - The clear braided vinyl tubing walls are thick and flexible enough to prevent kinks, ideal for working in confined areas. High quality material makes it uv-resistant, chemicals resistant.
Widely Application - High pressure PVC tubing applicable to industrial and agricultural, engineering, fish farming, and other fields. Ideal for oil, fuel, water, and air lines dispensing.
Characteristics:
1.100% virgin PVC materials,Non-toxic,Non smell.
2.Transparent, with small bending radius.
3 Has good adaptability to hard weather conditions and minus pressure
4.Soft and flexible.Anti abrasion,Anti-corrosion,Anti-aging，Anti-UV,long working life
5.Durable against the external impact,chemical and climate
6.Transparent, easy to check the contents.
| Inner Diameter | Outer Diameter | Working Pressure | Burst Pressure | weight | coil | |||
| inch | mm | mm | bar | psi | bar | psi | g/m | m |
| 5/32 | 4 | 8 | 10 | 150 | 50 | 750 | 49 | 100 |
| 1/5 | 5 | 10 | 12 | 180 | 40 | 600 | 76 | 100 |
| 1/4 | 6 | 11 | 12 | 180 | 36 | 540 | 87 | 100 |
| 5/16 | 8 | 13 | 10 | 150 | 30 | 450 | 105 | 100 |
| 3/8 | 10 | 15 | 10 | 150 | 30 | 450 | 130 | 100 |
| 1/2 | 12 | 18 | 9 | 135 | 27 | 405 | 185 | 100 |
| 5/8 | 16 | 22 | 8 | 120 | 24 | 360 | 230 | 50 |
| 3/4 | 19 | 25 | 6 | 90 | 18 | 270 | 270 | 50 |
| 7/8 | 22 | 28 | 5 | 75 | 15 | 225 | 305 | 50 |
| 1 | 25 | 31 | 5 | 75 | 15 | 225 | 340 | 50 |
| 1-1/4 | 32 | 40 | 4 | 60 | 12 | 180 | 590 | 40 |
| 1-1/2 | 38 | 46 | 4 | 60 | 12 | 180 | 690 | 40 |
| 1-3/4 | 45 | 56 | 4 | 60 | 12 | 180 | 1140 | 30 |
| 2 | 50 | 62 | 4 | 60 | 12 | 180 | 1380 | 30 |
| 2-1/2 | 64 | 78 | 4 | 60 | 12 | 180 | 2030 | 20 |
| 3 | 76 | 92 | 4 | 60 | 12 | 180 | 2750 | 20 |
