8 Inch HDPE Drain Pipe
Color: Black with bule line
Specification : 20-1200mm
Pressure : 0.6MPa SDR26,0.8MPa SDR21,1MPa SDR17,1.25MPa SDR 13.6,1.6MPa SDR 11
Main application: Water Supplying and Draining
Guarantee: More than 50 years
Product Description:
Advantages
1.Nontoxic
2.Corrosion Resistant
3.Lower Installation Costs
4.Higher Flow Capacity
5.Longevity: more than 50 years under proper use
6.Recycled and Environment-friendly
Features
1. It has the characteristics of light weight, high ring stiffness, convenient construction,transportation and installation,low installation cost, high ultraviolet resistance stability and good flexibility etc.With appropriate bending degree, HDPE double-wall corrugated pipe with a certain length can be slightly bent.Because of the uneven foundation in use, the pipe can be bent naturally which cannot make leakage.Compared with other pipes in same diameter,the flow rate of HDPE double-wall corrugated pipe is higher because of its smooth inner wall.Meanwhile,it has the characteristics of unblocked, easy maintenance,pressure resistance,low temperature resistance,high impact strength, acid and alkali resistance, corrosion resistance and long service life and so on.
2. Reasonable structure and excellent performance:HDPE double-wall corrugated pipe adopts annular structure wall pipe and optimized corrugated structure, so that the pipe has greater strength and appropriate flexibility per unit weight, which makes the raw material more efficient. After years of production and practice,the production technology is reliable and the product performance is stable.
3. Reliable connection to prevent leakage:HDPE double-wall corrugated pipe adopts reinforced design in socket and it is connected with sealing rubber ring which makes the pipe more firm and reliable before and after connection.And the strict control of the size of the socket joint makes the installation more convenient and leakage prevention more effective.
Product parameters
PN | 0.6MPa | 0.8MPa | 1.0MPa | 1.25MPa | 1.6MPa |
SDR | SDR26 | SDR21 | SDR17 | SDR13.6 | SDR11 |
DN | Thickness | Thickness | Thickness | Thickness | Thickness |
16 | 2 | ||||
20 | 2 | 2.3 | |||
25 | 2.3 | 3 | |||
32 | 2.3 | 2.4 | 3 | ||
40 | 2.3 | 2.3 | 3 | 3.7 | |
50 | 2.3 | 2.9 | 3.7 | 4.6 | |
63 | 2.3 | 2.5 | 3.6 | 4.7 | 5.8 |
75 | 2.9 | 3.6 | 4.5 | 5.6 | 6.8 |
90 | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 |
110 | 4.2 | 5.3 | 6.6 | 8.1 | 10 |
125 | 4.8 | 6 | 7.4 | 9.2 | 11.4 |
140 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
160 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
180 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
200 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
225 | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 |
250 | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
280 | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
315 | 12.1 | 15 | 18.7 | 23.2 | 28.6 |
355 | 13.6 | 16.9 | 21.1 | 26.1 | 32.2 |
400 | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 |
450 | 17.2 | 21.5 | 26.7 | 33.1 | 40.9 |
500 | 19.1 | 23.9 | 29.7 | 36.8 | 45.4 |
560 | 21.4 | 26.7 | 33.2 | 41.2 | 50.8 |
630 | 24.1 | 30 | 37.4 | 46.3 | 57.3 |
710 | 27.2 | 33.9 | 42.1 | 52.2 | - |
800 | 30.6 | 38.1 | 47.4 | 58.8 | - |
900 | 34.4 | 42.9 | 53.3 | ||
1000 | 38.2 | 47.7 | 59.3 | ||
1200 | 45.9 | 57.2 | 70.6 | ||
1400 | 53.9 | 66.7 | 82.4 |
Applications:
1.City water pipe network system.
2.Urban and rural drinking water pipeline .
3.Chemical industry, chemical fiber, food, forestry, printing and dyeing, pharmaceutical. light industry, paper-making, metallurgy Industrial pipeline.
4.Agricultural irrigation pipe.
FAQ
Q: How can we guarantee quality?
A: Always a pre-production sample before mass production;Always final Inspection before shipment.
Q: What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q: Could you calculate the shipping cost for me?
A: Of course, we honored to do that! Before freight, please well let us know which seaport or airport near your place.
Q: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q: Can I place sample order first?
A: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
