3 Inch Pvc Discharge Hose
Length: 100 Meters
Thickness: 2mm-4mm
Standard: ISO9001:2008/ROHS/UL/CE
Product introduction
Name: 3 inch pvc discharge hose
Specification: 1"-12"
Length: 100 Meters
Thickness: 2mm-4mm
Standard: ISO9001:2008/ROHS/UL/CE
Name: Layflat hose
PVC Material: Pvc compound
Burst Pressure: 27---30Bar
Working Pressure: 9---10Bar (120--140PSI)
Color: Red/blue/red/yellow/green/brown/lemon
Features
(1) Flexible PVC with high grade strength polyester yarn reinforcement, lightweight, aging resistant, abrasion resistant and compact for economical storage.
(2) supplies a range of high pressure, high performance agiculture irrigation pipe manufactured to meet many national and international standards.We also offer a range of water pipe accessories including couplings, branch pipes, jet spray nozzles and standpipes.
(3) Light weight, good flexibility, bright color, smooth
(4) Capable for keeping the flexibility and elasticity under the low-temperature water
(5) Resistant to abrasion, corrosion, high pressure and terrible weather.
(6) Ideal durable hose for irrigation and drainage in the farmland and garden. cement filing, river-way sand extraction, water discharge in the construction site, road building and so on
Construction
Tube and Cover: PVC, blue,orange,red.
Reinforcement: high tensile polyester braiding.
Characteristic
Light weight,Good flexibility.
Corrosion resistant,anti-aging.
Easy handle & storage.
Various colors available.
Assemblies and/or cut lengths available.
Non-toxic,Non-smell
Burst pressure 3 times working pressure.
Product parameters
Item Code | I.D | W.P. | B.P. | Length | Weight | Volume | |||
inch | mm | psi | bar | psi | bar | m/roll | kg/m | m3/roll | |
HK20 | 3/4" | 20 | 145 | 10 | 435 | 30 | 50 | 0.15 | 0.007 |
HK25-1 | 1" | 25 | 116 | 8 | 348 | 24 | 50 | 0.17 | 0.010 |
HK25-2 | 1" | 25 | 145 | 10 | 435 | 30 | 50 | 0.20 | 0.010 |
HK32-1 | 1-1/4" | 32 | 116 | 8 | 348 | 24 | 50 | 0.19 | 0.012 |
HK32-2 | 1-1/4" | 32 | 145 | 10 | 435 | 30 | 50 | 0.21 | 0.012 |
HK38-1 | 1-1/2" | 38 | 116 | 8 | 348 | 24 | 50 | 0.24 | 0.013 |
HK38-2 | 1-1/2" | 38 | 145 | 10 | 435 | 30 | 50 | 0.29 | 0.013 |
HK40-1 | 1-1/2" | 40 | 116 | 8 | 348 | 24 | 50 | 0.25 | 0.013 |
HK40-2 | 1-1/2" | 40 | 145 | 10 | 435 | 30 | 50 | 0.30 | 0.013 |
HK45-1 | 1-3/4" | 45 | 116 | 8 | 348 | 24 | 50 | 0.32 | 0.018 |
HK45-2 | 1-3/4" | 45 | 145 | 10 | 435 | 30 | 50 | 0.35 | 0.018 |
HK51-1 | 2" | 51 | 116 | 8 | 348 | 24 | 50 | 0.35 | 0.020 |
HK51-2 | 2" | 51 | 145 | 10 | 435 | 30 | 50 | 0.42 | 0.020 |
HK64-1 | 2.5" | 64 | 116 | 8 | 348 | 24 | 50 | 0.55 | 0.024 |
HK64-2 | 2.5" | 64 | 145 | 10 | 435 | 30 | 50 | 0.70 | 0.024 |
HK76-1 | 3" | 76 | 116 | 8 | 348 | 24 | 50 | 0.66 | 0.030 |
HK76-2 | 3" | 76 | 145 | 10 | 435 | 30 | 50 | 0.85 | 0.030 |
HK102 | 4" | 102 | 116 | 8 | 348 | 24 | 50 | 1.00 | 0.042 |
HK102 | 4" | 102 | 145 | 10 | 435 | 30 | 50 | 1.20 | 0.042 |
HK153 | 6" | 153 | 116 | 8 | 348 | 24 | 50 | 2.20 | 0.071 |
HK203 | 8" | 203 | 116 | 8 | 348 | 24 | 50 | 2.80 | 0.010 |
Applications
PVC lay flat hose is designed for light and heavy duty applications,the hoses are most commonly used in agricultural equipment where continuous water flow through irrigation systems is required. Other application include water pump, pool & spa, construction, mines and marine.
FAQ
Q: How can we guarantee quality?
A: Always a pre-production sample before mass production;Always final Inspection before shipment.
Q: What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q: Could you calculate the shipping cost for me?
A: Of course, we honored to do that! Before freight, please well let us know which seaport or airport near your place.
Q: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q: Can I place sample order first?
A: Yes, we will quote you different prices for small, medium and large qty. You can order with different price for different qty.
