Rubber 1 Inch Fuel Hose
Product Application of 3/4 1 Inch one Steel Wire Braid Hydraulic Rubber Gasoline fuel hose for dispensers
Our products are popular in the demestic market, at the same time, we enjoyed a good reputation from the foreign customers.
This hoses are extensively used to mining, metallurgical, oil, project machinery, chemical, agriculture field. E.g. Mine hydraulic fluid, oil exploration, crane, forging metallurgy, mining equipment, ships, injection molding machinery, agricultural machinery and various machines tools.
Characteristic:
1.100% New NBR Materials
2.Aging resistant; insulation; acid and alkaline resistant
3.Airtight; shock absorption, etc.
Temperature: -40℃ (-104 ℉ )to +100℃ (+212 ℉ )
Applications:
1, transportation: the shipbuilding industry applications.
2, radio, motor: telecommunications industries.
3, instruments, industrial instrumentation applications.
4, aerospace industry applications.
5, suitable for appliances, lighting, medical, beauty salons equipment and so on
SPECIFICATIONS FOR SAE 100 R1 AT / DIN EN 853 1SN | ||||||||
DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Min.Bend Radius | Weight | Length |
5 | 3/16 | 9.5 | 12.5 | 25 | 100 | 89 | 0.19 | 50/100 |
6 | 1/4 | 11.5 | 14.1 | 22.5 | 90 | 102 | 0.21 | 50/100 |
8 | 5/16 | 12.7 | 15.7 | 21.5 | 85 | 114 | 0.24 | 50/100 |
10 | 3/8 | 15.1 | 18.1 | 18 | 72 | 127 | 0.33 | 50/100 |
13 | 1/2 | 18.3 | 21.5 | 16 | 64 | 178 | 0.41 | 50/100 |
16 | 5/8 | 21.4 | 24.7 | 13 | 52 | 203 | 0.45 | 50 |
19 | 3/4 | 25.4 | 28.6 | 10.5 | 42 | 241 | 0.58 | 50 |
25 | 1 | 33.3 | 36.6 | 8.8 | 35 | 305 | 0.88 | 50 |
32 | 1 1/4 | 40.5 | 44.8 | 6.3 | 25 | 419 | 1.23 | 20-40 |
38 | 1 1/2 | 46.8 | 52.0 | 5 | 20 | 508 | 1.51 | 20-40 |
51 | 2 | 60.2 | 65.9 | 4 | 16 | 635 | 1.97 | 20-40 |
SPECIFICATIONS FOR SAE 100 R2 AT/ DIN EN 853 2SN | ||||||||
DN | Hose I.D | Wire O.D | Hose O.D | Working Pressure | Burst Pressure | Min.Bend Radius | Weight | Length |
5 | 3/16 | 11.5 | 14.1 | 41.4 | 166 | 90 | 0.32 | 50/100 |
6 | 1/4 | 12.7 | 15.7 | 40.0 | 160 | 100 | 0.36 | 50/100 |
8 | 5/16 | 14.3 | 17.3 | 36.0 | 140 | 115 | 0.45 | 50/100 |
10 | 3/8 | 16.7 | 19.7 | 33.1 | 132 | 130 | 0.68 | 50/100 |
13 | 1/2 | 19.8 | 23.1 | 27.6 | 110 | 180 | 0.80 | 50/100 |
16 | 5/8 | 23.0 | 26.3 | 25 | 100 | 200 | 0.94 | 50 |
19 | 3/4 | 27.0 | 30.2 | 21.5 | 86 | 240 | 1.20 | 50 |
25 | 1 | 34.9 | 38.9 | 16.5 | 66 | 300 | 1.35 | 50 |
32 | 1 1/4 | 44.5 | 49.6 | 12.5 | 50 | 420 | 2.15 | 20-40 |
38 | 1 1/2 | 50.8 | 56.0 | 9.0 | 36 | 500 | 2.65 | 20-40 |
51 | 2 | 63.5 | 68.6 | 8.0 | 32 | 630 | 3.42 | 20-40 |
