Ptfe Corrugated Hose
Application: compressed air, gas, steam, fuel, oil, chemical and pharmaceutical products, particularly suitable for steam piping on injection moulding machines, diathermic oil installations, charging lines for cryogenic gas, compressor discharge lines, automotive, pharmaceutical and food sectors. Solvents, pigments and paint transfer lines. Hydraulic lines in power stearing marine applications. Not suitable for molten alkali metals and halogens at high temperature.
Best flexibility corrosion resistance stainless steel 304 braided PTFE lined corrugated Antistatic hose
Antistatic PTFE hose has a very wide temperature range (from -200 to +260 degrees Celsius). Basically, it has corrosion resistance to all chemicals except some fluoride and alkaline metal liquid. Excellent mechanical properties include anti-aging, especially for bending and swinging applications, excellent fire retardancy. (in accordance with astm-d635 and D470 test procedures, It is defined as flame-retardant material in the air, with excellent insulation characteristics (regardless of its frequency and temperature), extremely low water absorption, and a series of unique properties such as self-lubricating and non sticky, low friction coefficient Very good wear resistance; application: Seal / gasket, ring material, wear plate / seat electricity, insulation parts, anti-corrosion industry, mechanical parts, lining, oil and natural gas, petrochemical industry, chemical industry, instrument and equipment manufacturers, etc
Character of PTFE
PTFE has the following excellent properties due to its strong carbon-fluorine bond and high molecular wieght:
1. Excellent weather resistance, long service life, no brittle fracture and no aging.
2. Resistant to strong acid and alkali, resistant to various corrosive chemicals.
3. Anti-adhesive, anti-moisture and ultraviolet, non-toxic.
4. With a very low friction coefficuent. non-flammable.
5. With very low evaporate transpiration rate, cold liquid is not volatile.
6. With excellent electrical charateristics (does not change with frequency and temperature changes)
7. Excellent mechanical properties, shock resistance and flexibility.
|
No.
|
Specification
|
ID(mm)
|
OD(mm)
|
Thickness(mm)
|
Working Pressure(bar)
|
Burst Pressure(bar)
|
|
1
|
1/8
|
3.5
|
6.6
|
1
|
326
|
1007.76
|
|
2
|
3/16
|
4.8
|
8
|
0.85
|
247
|
740.52
|
|
3
|
1/4
|
6.4
|
9.2
|
0.85
|
214.2
|
666.06
|
|
4
|
5/16
|
8
|
11
|
0.85
|
191.76
|
598.74
|
|
5
|
3/8
|
9.7
|
12.8
|
0.85
|
188.7
|
567.12
|
|
6
|
1/2
|
12.7
|
15.9
|
1
|
156
|
470.22
|
|
7
|
5/8
|
16
|
19.2
|
1
|
129.54
|
389.64
|
|
8
|
3/4
|
19
|
22.7
|
1.2
|
79.56
|
274.38
|
|
9
|
7/8
|
22.2
|
26
|
1.2
|
61.2
|
198.9
|
|
10
|
1
|
25
|
29.3
|
1.5
|
40.8
|
156.06
|
|
11
|
2
|
50
|
55.6
|
2
|
30.6
|
122.4
|
