1 Wire Braid High Pressure Hose DIN/EN 856 1SNK
Material: Synthetic Rubber
Surface: Black Wrapped
Reinforcement: High--tensile Wire Spiral
Product Description：
Name: 1 wire braid high pressure hose DIN/EN 856 1SNK
Constant operation: -40 °C +100 °C (-40 °F +212 °F)
air max T = +70 °C (+160 °F)
Safety factor: 1:4
Complete Range of Size from 3/16" to 2"
Various Color: Black, Red, Blue, Yellow, Gray etc.
Tube: Oil resistant synthetic rubber
Cover: Abrasion and weather resistant synthetic rubber
Temperature range: -40 degree centigrade To +100 degree centigrade
Product parameters
Hose Size ID | Hose OD | Max.Working | Min.Bend Radius | Min.Burst Pressure | Weight | |||||
in | DIN | in | mm | psi | mpa | in | mm | psi | mpa | kg/m |
3/16 | 4.8 | 0.47 | 11.9 | 3630 | 25 | 3.5 | 89 | 14520 | 100.1 | 0.91 |
1/4 | 6.4 | 0.53 | 13.6 | 3270 | 22.5 | 4 | 102 | 13080 | 90.2 | 0.21 |
5/16 | 7.9 | 0.59 | 15.1 | 3120 | 21.5 | 4.5 | 114 | 12480 | 86 | 0.24 |
3/8 | 9.5 | 0.68 | 17.5 | 2615 | 18 | 5 | 127 | 10460 | 72.1 | 0.33 |
1/2 | 12.7 | 0.81 | 20.7 | 2320 | 16 | 7 | 178 | 9280 | 64 | 0.41 |
5/8 | 15.9 | 0.93 | 23.8 | 1890 | 13 | 8 | 203 | 7560 | 52.1 | 0.45 |
3/4 | 19 | 1.09 | 27.8 | 1530 | 10.5 | 9.5 | 241 | 6120 | 42.2 | 0.58 |
1 | 25.4 | 1.4 | 35.8 | 1280 | 8.8 | 12 | 305 | 5120 | 35.3 | 0.91 |
1 1/4 | 31.8 | 1.69 | 43.1 | 920 | 6.3 | 16.5 | 419 | 3680 | 25.4 | 0.21 |
1 1/2 | 38.1 | 1.97 | 50.1 | 730 | 5 | 20 | 508 | 2920 | 20.1 | 0.24 |
2 | 50.8 | 2.5 | 63.6 | 580 | 4 | 25 | 635 | 2320 | 16 | 0.33 |
Product category
MAIN PRODUCT TYPE | PRODUCT DETAILS |
| Hydraulic Hose and Fitting | Steel Wire Braided Reinforcement Hose(R1 R2 1SN 2SN 1SC 2SC R16 R17) |
Steel Wire Spiral Reinforcement Hose(2SP 4SP 4SH 6SP R9 R12 R13 R15) | |
Fibre Braided Covered Hose (R5) | |
Acid and Alkali Resistant Rubber Hose | |
Air Screw Compressor Hose | |
Middle Pressure Fibre Reinforcement Hose(R3 R6 1TE 2TE 3TE) | |
Thermoplastic Hose(SAE100R7 SAE100R8) | |
Nylon Hose(Single and Double Hose) | |
Industrial Hose | Air/Water/Oil/Fuel/Steam/Chemical Suction and Discharge Hose |
Special Hose | Concrete Pump Hose, High Pressure Drilling Hose, Inflatable Packers |
Machine Equipment | Crimping Machine, Cutting Machine |
Application: used for Petroleum Base Hydraulic Fluids,construction machinery,Petrochemical,coal mine,Hydraulic system,oilfield,agricultural machinery,high pressure hydraulic systems in industry and agriculture. This Steel Wire Hose is mainly intended for diverse applications in the fields of forestry, agriculture, construction and others. It is integrated with a bend radius capability which allows an intuitive mounting and routing. This also enables a longer hose life in various curving applications and some of the bent tube fitting needs. |  |
FAQ
Q: Are you a manufacturer or trading company?
A: We are a specialized manufacturer.
Q: How about discount?
A: Price is based on products and order quantity.
Q: How about your after-sales service?
A: As a manufacturer, we offer promote technology support for all problems and questions.
Q: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q: What is your sample policy?
A: We can supply the sample if we have ready parts in stock.
